24V Buck Module 3A
Size: 18.2 (Long) * 10.3 (WIDE) * 3.8 (High) mm
1: The use of new original American imports of chips.
2: Output current maximum 3 A, long time running 2.1A, ample allowance. 3 A runs 20 seconds or so chips into the overheat protection reboot, which can be worked on by cooling the chip on the 3 A current.
3: The use of a new design, circuit design does not require electrolytic capacitors and tantalum capacitors (electrolytic capacitor life is short, tantalum capacitor explosion risk). Use of the current high-end circuit on the large size of solid-state ceramic Capacitor (MCC) 3.
4: The use of non-isolated DC synchronous rectification, circuit conversion efficiency is very high, in 6.5V to 5V 0.7A when the efficiency of $number. $number, 12V to 5V 1 A also reached 94%.
5: The use of integrated inductor, ultra-low internal resistance, maximize the conversion efficiency. Lower calorific value, higher efficiency, lower than ordinary shielding inductance.
6: Ultra Small volume, 18 (long) $number (wide) * 3.8 (high) mm, Mini.
7: Ultra-low static current, 12V input, output 5V voltage, LED lamp led case-static current less than 0.45 ma. The connection in the car battery no need to add a switch, can be connected to the cigarette line, or ACC power cord.
8: Output integration can reconcile fixed voltage, fixed output is not required to customize, directly on the board spot welding, special voltage can be adjusted with potentiometer, very strong versatility.
9: The output with LED light indicator, convenient and intuitive indication of voltage output.
10: With the enabling port, the default mode of work, low level shutdown, to facilitate the control
11: Can be used to replace 78 series of linear regulators, such as 7805 7812 and so on.



Product parameters
Module properties: Non-isolated buck module (Buck) synchronous rectifier Input Voltage: DC 4.5-24v
Output voltage: Can be reconciled fixed to lose hi, the back can be selected fixed mountain voltage adjustable range (0.8-12v), fixed voltage (3). 3V 5V 9V 12V)
Lose! 丨 Current: Max 3A (full load please pay attention to the heat dissipation), the actual test input 12V 1. No special treatment of heat dissipation within 5A. Conversion efficiency: Highest 97. 5% (6.5 ext. 5V 0·7 a)
Switching frequency: 500KHZ output ripple: 20mV about (12V to 5v3a)
Operating Temperature: Industrial Grade (-4010 to +851c) (the higher the ambient temperature, the smaller the output power)
Output over voltage protection: No load temperature rise: 40°c static current: 0.85 ma load adjustment rate: Chevalier 1%
Voltage Adjustment Rate: 0.5%
Dynamic response speed: $number 200uS
Lost! h Short Circuit protection: have (do not l<: time short circuit)
Input reverse protection: none
Enable control: Have, high level work, low level stop work, still level is 2-5v, low level is around 0V. Default internal with pull up to input TF.
Wiring mode: Welding input mode: Welding output: welding/pin welding hole spacing. 2.54 mm
